Main spare parts list:
1. Laser source - Raycus (MAX, JPT, IPG for option)
2. Laser cutting head - Raytools (Precitec & automatic focus for option)
3. Chiller - Hanli
4. Servo drive - LEAD-MOTION (Germany)
5. Reducer - NIDEC-SHIMPO (Japan)
6. Rack - LEAN (Germany)
7. Guide - HIWIN (Taiwan)
8. System - Cypcut
Technical Parameters
| Main components & parts | |||
| ComponentsComponents | Specification | Quantity | |
| #1 | Laser generator | 1000W/1500W/2000W/3000W | 1 pcs |
| #2 | Laser cutting head | manual focusing | 1 pcs |
| #3 | CNC system | special cutting system CYPCUT, height adjustment system ,Industrial Personal Computer (IPC) | 1 pcs |
| #4 | Machine tool | machine tool body, beam, metal sheet, exchange platform | 1 pcs |
| #5 | Transmission system | reducer & gear rack | 3 set |
| guide rail | 4 set | ||
| #6 | Servo system | driver & motor | 4 set |
| #7 | Lubrication device | electric lubricating pump | 1 pcs |
| #8 | Gas circuit | proportional valve, solenoid valve, check valve | 1 pcs |
| #9 | Electric circuit | contactor, circuit breaker, electric relay | 1 pcs |
Description
1. Fiber laser cutter power: 1000W, 1500W, 2000W, 3000W, 4000W, 6000w, 10000w, 12000w, etc.
2. Fiber laser generator: JPT, RAYCUS, MAX, NIGHT, IPG etc.
3. Fiber laser cutter materials: Iron, aluminum, carbon steel, stainless steel, copper, hardware and another metal sheet
materials.
4. Other machine optional parts can be chosen, such as, rotary axis, exchange working table, full cover, etc.
5. China Top fiber laser machine cutting manufactuers, JNLINK, best price and high quality, with CE etc certificates.
Product application
Application Materials:
Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, If you equipped with the rotary axis, Metal Plate, Tubes and Pipes, all ok.
Application Industries:
CNC Fiber Laser Cutting Machines are widely used in manufacture Billboard, Signs, Advertising, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.
FAQ
Q: How can I get the sample to check you quality ?
A: If you want to marking sample to check the quality, we can help you do this. first you need to provide the logo or design to us, free mark samples can be provided.
Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.1. What material you want to cut,stainless steel,carbon steel or other? 2. What thickness do you want to cut?
Q: Does the machine can be customized according to my requirements ?
A: Sure, we have a strong technical team and have rich experience. Our goal is to make you satisfied.
Q: How to operate the machine ?
A: We will deliver English manual and video with the machine to you. If you still need our help, please contact us.
Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across theworld, We need your machines running in order to keep your business running.
Details
- Application: LASER CUTTING
- Applicable Material: Acrylic, Metal
- Condition: New
- Laser Type: Fiber Laser
- Cutting Area: 3000*1500mm
- Cutting Speed: 1000-26000mm/min
- Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
- Cutting Thickness: 1-30mm
- CNC or Not: Yes
- Cooling Mode: WATER COOLING
- Control Software: CypCut
- Laser Source Brand: IPG/MAX
- Laser Head Brand: Chylaser
- Servo Motor Brand: Yaskawa
- Guiderail Brand: HIWIN
- Control System Brand: Cypcut
- Weight (KG): 7000 KG
- Key Selling Points: High-accuracy
- Warranty: 3 years
- Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 3 years
- Core Components: laser
- Mode of Operation: continuous wave
- Configuration: 3-axis
- Products handled: Sheet Metal and Tube
- Feature: Water-cooled
- Certification: ISO
- After-sales Service Provided: Video technical support
- After Warranty Service: Field maintenance and repair service
- Local Service Location: Malaysia
